LP12C/10C/08C/062C Plane Precision Ring Polisher (Polyurethane polishing)

Mainly used for precision high speed polishing of planar elements such as high precision optical glass, quartz, crystal.ceramics, silicon wafer, sapphire and so on. It has three workpiece calipers.

Main technical specification

Product Model	LPI2C	LPI0C	LP08C	LP062C
Millstone size(granite)	Ф1200 mm	Ф1000 mm	Ф800 mm	Ф620 mm
Workpiece ring size	Ф500xФ400x50	Ф410xФ350x40	Ф340xФ280x40	Ф250xФ200x40
Jumpiness of millstone	≤0.06mm	≤0.06mm	≤0.05mm	≤0.05mm
Jumpiness of single point	≤0.01mm	≤0.01mm	≤0.01mm	≤0.01mm
Location number	3pcs	3pcs	3pcs	3pcs
Millstone rotating speed	0,6~30RPM	0,8~40RPM	0,10~50RPM	0,10~50RPM
Processing scope	≤Ф400mm	≤Ф350mm	≤Ф280mm	≤Ф200mm
Total power	6.3kW/380V	3.6kW/380V	2.7kW/380V	2.3kW/380V
Weight	About2100kg	About1500kg	About1300kg	About800kg
Size	1800 x 1800x1500(mm)	1550 x 1500 x 1500(mm)	1450 x 1350 x 1600(mm)	1150x950x 1600(mm)
All machine can be designed and manufactured as required.
